PVC Unarmoured Cables

PVC Unarmoured Cables

Cable Structure

Generally confirming to DIN VDE 0250, IEC 60332-1, Generally to AS/NZS 5000:2003, CE Directive 72/23/EEC

Conductor : Material - Copper According to VDE 0295 class 1 or 2 (IEC 60228,IS 8130)
Insulation : PVC Type A as per IS:5831
Inner Sheath : PVC
Outer Sheath : PVC TYPE ST-1 OF IS : 5831
Technical Data
Operating Temp : -20°C to max.+80°C
Nominal Voltage : 1100 V
Test Voltage : 3000 V
Insulation resistance : Min. 10 MΩ x km
Min. bending radius : Single Core : 15X Overall diameter
Multi Core : 12X Overall diameter
Flame propagation : Flame retardant test as per IEC 60332-1
Application
 PVC Unarmoured Cables
-   Power cables for energy supply are installed outdoors, in underground, in water, indoors, in cable ducts, power stations, for industry and distribution boards as well as in subscriber networks, where mechanical damages are not to be expected.
 Standard length cable packing
-   Coils 100, 200, 300, 500, 1000 m. in wooden reels

Color Coding: AS IS 1554 ( Indian Standard )

Single Core 2 Core 3 Core 4 Core 5 Core
Red or Black Red, Black Red, Yellow, Blue Red, Yellow, Blue, Black Red, Yellow, Blue, Black, Grey

Color coding: AS IEC 60502 Part-1, B.S. 6346

Single Core 2 Core 3 Core 4 Core 5 Core
Black or Yellow/Green Blue and Brown or Yellow-Green, and Black Blue, Brown, Black, Grey, or Yellow/Green, Blue, Brown Blue, Brown, Black, Grey or Yellow/Green, Brown, Black, Grey Blue, Brown, Black, Grey, Black or Yellow/Green, Blue, Brown, Black, Grey

JAINSON 1.1 kV 3 CORE COPPER CONDUCTOR PVC INSULATED , INNER SHEATHED UN ARMOURED PVC SHEATHED CABLES (IS : 1554 PART 1 ) CABLE CODE : YY

Size (MM2) INSULATION PVC THICKNESS IN MM (NOM.) INNER SHEATH PVC THICKNESS IN MM (MIN.) OUTER SHEATH PVC THICKNESS IN MM (MIN.) APPROX OUTER SHEATH O/D IN MM APPROX WEIGHT OF CABLE (KGS./KM) MAX.DC CONDUCTOR RESISTANCE at 20° C (Ohm/Km) Current Ratings (Amp.)
Direct in Ground In Air
3 C X 1.5 0.80 0.30 1.80 11.60 201 12.10 21 17
3 C X 2.5 0.90 0.30 1.80 12.80 256 7.41 27 24
3 C X 4 1.00 0.30 1.80 14.95 365 4.61 36 30
3 C X 6 1.00 0.30 1.80 16.00 447 3.08 45 39
3 C X 10 1.00 0.30 1.80 18.15 623 1.83 60 52
3 C X 16 1.00 0.30 2.00 20.70 877 1.15 77 66
3 C X 25 1.20 0.30 2.00 21.30 1138 0.727 99 90
3 C X 35 1.20 0.30 2.00 23.25 1472 0.524 120 110
3 C X 50 1.40 0.30 2.00 26.55 2027 0.387 145 135
3 C X 70 1.40 0.40 2.20 29.65 2658 0.268 175 165
3 C X 120 1.60 0.40 2.20 36.25 4409 0.153 240 230
3 C X 150 1.80 0.50 2.40 40.40 5484 0.124 270 265
3 C X 185 2.00 0.50 2.40 44.00 6632 0.0991 300 305
3 C X 240 2.20 0.60 2.60 49.20 8412 0.0754 345 355
3 C X 300 2.40 0.60 2.80 54.30 10434 0.0601 385 400
3 C X 400 2.60 0.70 3.20 61.70 13823 0.0470 425 455

JAINSON 1.1 kV 4 CORE COPPER CONDUCTOR PVC INSULATED , INNER SHEATHED UN ARMOURED PVC SHEATHED CABLES (IS : 1554 PART 1 ) CABLE CODE : YY

Size (MM2) INSULATION PVC THICKNESS IN MM (NOM.) INNER SHEATH PVC THICKNESS IN MM (MIN.) OUTER SHEATH PVC THICKNESS IN MM (MIN.) APPROX OUTER SHEATH O/D IN MM APPROX WEIGHT OF CABLE (KGS./KM) MAX.DC CONDUCTOR RESISTANCE at 20° C (Ohm/Km) Current Ratings (Amp.)
Direct in Ground In Air
4 C X 1.5 0.80 0.30 1.80 12.50 235 12.10 21 17
4 C X 2.5 0.90 0.30 1.80 13.80 303 7.41 27 24
4 C X 4 1.00 0.30 1.80 16.25 438 4.61 36 30
4 C X 6 1.00 0.30 1.80 17.45 541 3.08 45 39
4 C X 10 1.00 0.30 2.00 20.25 782 1.83 60 52
4 C X 16 1.00 0.30 2.00 22.90 1095 1.15 77 66
4 C X 25 1.20 0.30 2.00 25.35 1361 0.727 99 90
4 C X 35 1.20 0.30 2.00 27.85 1770 0.524 120 110
4 C X 50 1.40 0.30 2.20 32.40 2469 0.387 145 135
4 C X 70 1.40 0.40 2.20 35.85 3211 0.268 175 165
4 C X 95 1.60 0.40 2.40 41.25 4358 0.193 210 200
4 C X 120 1.60 0.40 2.40 44.70 5386 0.153 240 230
4 C X 150 1.80 0.50 2.60 49.55 6664 0.124 270 265
4 C X 185 2.00 0.50 2.80 54.70 8134 0.0991 300 305
4 C X 240 2.20 0.60 3.00 60.90 10275 0.0754 345 355
4 C X 300 2.40 0.60 3.40 67.90 12838 0.0601 385 400
4 C X 400 2.60 0.70 3.60 76.75 16919 0.0470 425 455
